The Cube® Series
INDU-ELECTRIC Proudly Presents the CUBE® Series – Our most Compact line of Non-Conductive Power Distribution Boxes
US Patents # 7848085 / # D656,099S
-
Recessed Handle
-
Shock Absorbing Molded Rubber Corners
-
100% Rated Hydraulic Magnetic Breakers For Continuous Use At Full Rated Output
-
Rugged Non-Conductive Enclosure
-
Recessed Branch Devices & Labeling
-
Fully Enclosed Color Coded Cam Covers
Custom Configurations Quotes Next Business Day – Call us today!
The Cube® Series
We are proud to offer an extensive and innovative product line representing state of the art in power distribution equipment. Multiple configurations such as Cam, Pin & Sleeve, 19 Pin, Straight
Blade, Twistlock and GFCI are available in standard or custom configurations. Our enclosures are non-conductive, UL 94 V0 rated and virtually indestructible. US Patent #7848085
001 CUBE®
| Input Device: | 400A 3Ø Locking Cam 1 Pass Through | |
| Output Device: | 12- 20A 120V Duplex Outlets | |
| Protected By: | 12- 20A 1P Rocker Breaker | |
| Model-Nr.: | CB1-5WPT-12x520 | |
| Dimensions: | 15“L x 10“W x 8,25“H |
002 CUBE®
| Input Device: | 80A 3Ø Locking Cam | |
| Output Device: | 12- 20A 120V Duplex Outlets | |
| Protected By: | 12- 20A 1P Rocker Breaker | |
| Model-Nr.: | CB4-5W-12x520 | |
| Dimensions: | 10“L x 10“W x 8,25“H |
003 CUBE®
| Input Device: | 400A 3Ø Locking Cam 1 Pass Through | |
| Output Device: | 24- 20A 120V Duplex Outlets | |
| Protected By: | 24- 20A 1P Rocker Breaker | |
| Model-Nr.: | CB2-5WPT-24x520 | |
| Dimensions: | 15“L x 10“W x 10.75“H |
004 CUBE®
| Input Device: | 400A 3Ø Locking Cam | |
| Output Device: | 6- 30A 120/208V L21-30 | |
| Protected By: | 6- 30A 3P Breaker | |
| Model-Nr.: | CB4-5W-6xL2130 | |
| Dimensions: | 10“L x 11“W x 8.25“H |
Fully Customizable with L15-20/L15-30/L21-20/L5-20/L5-30/L6-20/L6-30/L14-20/L14-30 Twist-Locks
005 CUBE®
| Input Device: | 400A 3Ø Locking Cam 1 Pass Through | |
| Output Device: | 6- 30A 120/208V L21-30 | 3- 20A 120V Duplex Outlets* |
| Protected By: | 6- 30A 3P Breaker | 3- 20A 1P Breaker* |
| Model-Nr.: | CB2-5WPT-6xL2130-3x520 | |
| Dimensions: | 15“L x 10“W x 10.75“H |
Fully Customizable with L15-20/L15-30/L21-20/L5-20/L5-30/L6-20/L6-30/L14-20/L14-30 Twist-Locks
006 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Output Device: | 4- 20A 120/208V L21-20 | 4- 30A 120/208V L21-30 |
| 3- 20A 120V Duplex Outlets* | ||
| Protected By: | 4- 20A 3P Breaker | 4- 30A 3P Breaker |
| 3- 20A 1P Breaker* | ||
| Model-Nr.: | CB2-5WPT-4xL2130-4xL2120-3x520 | |
| Dimensions: | 15“L x 10“W x 10.75“H |
*Optional 3-20A Duplex Courtesy Outlets; Fully Customizable with L15-20/L15-30/L21-20/L5-20/L5-30/L6-20/L6-30/L14-20/L14-30 Twist-Locks
007 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Output Device: | 12- 30A 120/208V L21-30 | 3- 20A 120V Duplex Outlets* |
| Protected By: | 12- 30A 3P Breaker | 3- 20A 1P Breaker* |
| Model-Nr.: | CB3-5WPT-12xL2130-3x520 | |
| Dimensions: | 21.5“L x 10“W x 10.75“H |
*Optional 3-20A Duplex Courtesy Outlets; Fully Customizable with L15-20/L15-30/L21-20/L5-20/L5-30/L6-20/L6-30/L14-20/L14-30 Twist-Locks
008 CUBE®
| Input Device: | 100A 3Ø Locking Cam | |
| Output Device: | 3- 20A 120V Duplex Outlets | 4- 20A 120/208V L21-20 |
| Protected By: | 3- 20A 1P Breaker | 4- 20A 3P Breaker |
| Model-Nr.: | CB4-5W-4xL2120-3x520 | |
| Dimensions: | 10“L x 11“W x 8.25“H |
Fully Customizable with L15-20/L15-30/L21-20/L5-20/L5-30/L6-20/L6-30/L14-20/L14-30 Twist-Locks
009 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Output Device: | 2- 20A 120V Duplex Outlets | 4- 20A 120V 6 Circuits 19Pin |
| Protected By: | 26- 20A 1P Rocker Breaker | |
| Model-Nr.: | CB2-5WPT-4x19P120 | |
| Dimensions: | 15“L x 10“W x 10.75“H |
010 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Output Device: | 6- 20A 120V 6 Circuits 19Pin | |
| Protected By: | 38- 20A 1P Rocker Breaker | |
| Model-Nr.: | CB3-5WPT-6x19P120 | |
| Dimensions: | 24“L x 12“W x 11.75“H |
011 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Output Device: | 12- 20A 120V Duplex Outlets | 2- 20A 120V 6 Circuits 19Pin |
| Protected By: | 24- 20A 1P Rocker Breaker | |
| Model-Nr.: | CB2-5WPT-2x19P120-12x520 | |
| Dimensions: | 15“L x 10“W x 10.75“H |
012 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Output Device: | 2- 20A 120V Duplex Outlets | 2- 20A 240V 6 Circuit 19 Pin |
| Protected By: | 2- 20A 1P Breaker | 12- 20A 2P Breaker |
| Model-Nr.: | CB2-5WPT-2x19P240-2x520 | |
| Dimensions: | 15“L x 10“W x 10.75“H |
013 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Output Device: | 2- 20A 240V 6 Circuit 19Pin | 4- 20A 250V L6-20 |
| Protected By: | 16- 20A 2P Breaker | |
| Model-Nr.: | CB2-5WPT-2x19P240-4xL620 | |
| Dimensions: | 15“L x 10“W x 10.75“H |
014 CUBE®
| Input Device: | 400A 3Ø Locking Cam | |
| Output Device: | 2- 20A 120V Duplex Outlets | 1- 20A 240V 6 Circuit 19Pin |
| 6- 20A 250V Twistlock | ||
| Protected By: | 2- 20A 1P Breaker | 12- 20A 2P Breaker |
| Model-Nr.: | CB2-5W-1x19P240-6xL620-2x520 | |
| Dimensions: | 15“L x 10“W x 10.75“H |
015 CUBE®
| Input Device: | 100A 3Ø Locking Cam | |
| Output Device: | 3- 20A 120V Duplex Outlets | 2- 20A 120V 6 Circuit 19Pin |
| Protected By: | 15- 20A 1P Rocker Breaker | |
| Model-Nr.: | CB4-5W-2x19P120-3x520 | |
| Dimensions: | 10“L x 10“W x 8.25“H |
016 CUBE®
| Input Device: | 400A 3Ø Locking Cam | |
| Output Device: | 3- 20A 120V Duplex Outlets | 2- 20A 240V 6 Circuit 19Pin |
| Protected By: | 3- 20A 1P Breaker | 12- 20A 2P Breaker |
| Model-Nr.: | CB1-5W-2x19P240-3x520 | |
| Dimensions: | 13“L x 10“W x 8.25“H |
017 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Output Device: | 4- 20A 240V 6 Circuit 19Pin | 2- 20A 120V Duplex Outlets |
| Protected By: | 24- 20A 2P Breaker | 2- 20A 1P Breaker |
| Model-Nr.: | CB3-5WPT-4x19P240-2x520 | |
| Dimensions: | 24“L x 12“W x 11.75“H |
035 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Output Device: | 4- 20A 240V 6 Circuit 19Pin | 4- 20A 120V 6 Circuit 19Pin |
| 2- 20A 120V Duplex Outlets | ||
| Protected By: | 24- 20A 2P Breaker | 2- 20A 1P Breaker |
| Model-Nr.: | CB3-5WPT-4x19P208_120-Dual | |
| Dimensions: | 24“L x 12“W x 11.75“H |
036 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Output Device: | 8- 20A 120V 6 Circuit 19Pin | 2- 20A 120V Duplex Outlets |
| Protected By: | 50- 20A 1P Breaker | |
| Model-Nr.: | CB3-5WPT-8X19P120 | |
| Dimensions: | 24“L x 12“W x 11.75“H |
018 CUBE®
| Input Device: | 400A 1Ø Locking Cam | 1 Pass Through |
| Output Device: | 6- 50A 120/240V 3P 4W | CS6369 Twistlocks |
| 2- 20A 120V Duplex Outlets | ||
| Protected By: | 6- 50A 2P Breaker | 2- 20A 1P Breaker |
| Model-Nr.: | CB2-4WPT-6xCS6369-2x520 | |
| Dimensions: | 15“L x 10“W x 10.75“H |
Also available as 5 Wire 3Ø Version
019 CUBE®
| Input Device: | 400A 1Ø Locking Cam | 1 Pass Through |
| Output Device: | 2- 20A 120V Duplex Outlets | 4- 50A 120/240V 14-50 |
| 2- 30A 120V Straight Blades | ||
| Protected By: | 2- 20A 1P Breaker | 4- 50A 2P Breaker |
| 2- 30A 1P Breaker | ||
| Model-Nr.: | CB2-4WPT-4x1450-2x30RV | |
| Dimensions: | 15“L x 10“W x 10.75“H |
Also available as 4x30A / 2x50A RV Combo
020 CUBE®
| Input Device: | 220A 1Ø Locking Cam | |
| Output Device: | 4- 20A 120/240V 3P 4W | CS6369 Twistlocks |
| 2- 20A 120V Duplex Outlets | ||
| Protected By: | 4- 50A 2P Breaker | 2- 20A 1P Breaker |
| Model-Nr.: | CB4-4W-4xCS6369-2x520 | |
| Dimensions: | 10“L x 10“W x 8.25“H |
021 CUBE®
| Input Device: | 230A 1Ø Locking Cam | |
| Output Device: | 4- 50A 120/240V 14-50 | 2- 30A 120V Straight Blades |
| Protected By: | 4- 50A 2P Breaker | 2- 30A 1P Breaker |
| Model-Nr.: | CB4-4W-4x1450-2x30RV | |
| Dimensions: | 10“L x 10“W x 8.25“H |
022 CUBE®
| Input Device: | 100A 120/208V 4P 5Wire | Pin & Sleeve Male Inle |
| Output Device: | 1- 20A 120V Duplex Outlets | 5- 20A 120/208V L21-20 |
| Protected By: | 1- 20A 1P Breaker | 5- 20A 3P Breaker |
| Model-Nr.: | CB4-1PS-5xL2120-1x520 | |
| Dimensions: | 10“L x 10“W x 8.25“H |
023 CUBE®
| Input Device: | 60A 120/208 4P 5Wire | Pin & Sleeve Male Inlet |
| Output Device: | 9- 20A 120V Duplex Outlets | |
| Protected By: | 9- 20A 1P Rocker Breaker | |
| Model-Nr.: | CB4-6PS-9x520 | |
| Dimensions: | 10“L x 10“W x 8.25“H |
037 CUBE®
| Input Device: | 100A 3Ø Locking Cam Tail | |
| Output Device: | 2- 20A 120V Duplex Outlets | 3- 100A 120V Stage Pin |
| Protected By: | 2- 20A 1P Breaker | 3- 100A 120V 1P Breaker |
| Model-Nr.: | CB-C30-TAIL | |
| Dimensions: | 13“L x 10“W x 8.25“H |
025 CUBE®
| Input Device: | 400A 1Ø Locking Cam | 1 Pass Through |
| Output Device: | 2- 20A 120V Duplex Outlets | 4- 100A 120V Stage Pin |
| Protected By: | 2- 20A 1P Breaker | 4- 100A 120V 1P Breaker |
| Model-Nr.: | 400A Stage Pin Distro | |
| Dimensions: | 15“L x 10“W x 10.75“H |
026 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Output Device: | 2- 20A 120V Duplex Outlets | 6- 100A 120V Stage Pin |
| Protected By: | 2- 20A 1P Breaker | 6- 100A 120V 1P Breaker |
| Model-Nr.: | 600A Stage Pin Distro | |
| Dimensions: | 17,75“L x 10“W x 10.75“H |
027 CUBE®
| Input Device: | 400A 3Ø Locking Cam | 1 Pass Through |
| Input Device: | 2- 20A 120V Duplex Outlets | 3- 100A 120V Stage Pin |
| 3- 100A 120V Stage Pin | ||
| Protected By: | 2- 20A 1P Breaker | 3- 100A 120V 1P Breaker |
| 3- 100A 120V 2P Breaker | ||
| Model-Nr.: | 900A Stage Pin Distro | |
| Dimensions: | 15“L x 10“W x 10.75“H |
028 CUBE®
| Input Device: | 400A 3Ø 6Wire Locking Cam | 1 Pass Through |
| Output Device: | 2- 20A 120V Duplex Outlets | 6- 100A 120V Stage Pi |
| 3- 100A 240V Stage Pin | ||
| Protected By: | 2- 20A 1P Breaker | 6- 100A 2P Breaker |
| 3- 100A 2P Breaker | ||
| Model-Nr.: | 1200A Stage Pin Distro | |
| Dimensions: | 24“L x 12“W x 11.75“H |
Additional Standard Studio Stage Pin Configurations Available (300A/900A/Pigtail)
029 CUBE®
| Input Device: | 400A 3Ø Locking Cam | |
| Output Device: | 3 Rows 400A 3Ø Locking Cam | |
| Protected By: | NA | |
| Model-Nr.: | CB-SPI-1-3 | |
| Dimensions: | 15“L x 8.5“W x 8.25“H |
030 CUBE®
| Input Device: | 2 Rows of Parallel 400A (2400A Total) | 3Ø Locking Cam |
| Output Device: | 3 Rows 400A 3Ø Locking Cam | |
| Protected By: | NA | |
| Model-Nr.: | CB-SPI-2-3 | |
| Dimensions: | 15“L x 8.5“W x 10.75“H |
031 CUBE®
| Input Device: | 2 Rows of Parallel 400A (2400A Total) | 3Ø Locking Cam (Double Neutral) |
| Output Device: | 6- Rows of 5Wire (Double Neutral) | Locking Cam |
| Protected By: | NA | |
| Model-Nr.: | IND-SPI-2400 (2-6 Spider) | |
| Dimensions: | 23“L x 9“W x 14.25“H |
Also available as 4-4 (4800A) Spider
